ZT-4 Dual Wideband AFR Meter & ZR-4 Dual AFR Gauge Bundle by Zeitronix
Zeitronix Zt-4 Dual Wideband Air/Fuel ratio meter is a simple to use high quality, stand-alone system for carbureted and electronic fuel injection engines. The new Zt-4 has the same high quality, high precision air fuel ratio readings as our signature Zt-2 wideband. The Zt-4 supports wideband air fuel ratio and lambda readings, adjustable simulated narrowband outputs and configurable linear wideband outputs for ease of use with engine management systems and 3rd party gauges.
No matter if you have a stand alone engine management system, a piggy back fuel control or a carbureted engine. The Zt-4 Wideband Air Fuel Ratio Meter is a must for serious tuners! Finally you can tune for more power, closer to the edge, precisely monitoring both banks of V engine Air/Fuel ratio. Optional datalogging up to 9 hours of data with a blazing rate of 65 samples per second per graph. The Zeitronix Data Logger Software can be utilized as a real time display when using a standard Zt-4 kit with or without the ZR-4 or DashDAQ displays.
The Zt-4 communicates with the PC Laptop via the serial port using optional serial cable. The Zeitronix Data Logger (ZDL) software records up to 9 hours of data per single file. Many different screen display options are available including plots, text and dashboard views and uses a black plot background for easy night tuning. Logging start, stop and pause are accessible from keyboard shortcuts. The ZDL software supports excel CSV and text data export.
Clean and easy plug and play installation: power and display information is provided using one wire connecting to the Zt-4 GAUGE / DATA port. The ZR-4 cable length is 5 ft (1.5m) and can be extended if needed.
Features
- 0.1 AFR accuracy
- Operating voltage 10V to 18V
- Switching power supply for oxygen sensor heaters
- Precise sensor temperature control
- Reverse polarity protection
- Integrated self resettable fuse
- Positive lock connectors
- Protected inputs and outputs
- Flexible Plug and Play Sensor Harness with a small, easy to route through the fire wall, connector
- Optional logging serial cable available
- Easy to install plug and play kit
- Two Adjustable Narrowband Switching Point
- Two configurable Wideband Analog Outputs
- 2 Bosch Wideband O2 sensor Inputs
- Simulated and adjustable switching point Narrowband Outputs to feed a stock ECU
- 2 Linear Wideband Outputs (configurable with a default setup of AFR = Volts * 2 + 9.6
- Serial data output to the Zeitronix ZR-4 AFR or DashDAQ displays
- Serial data output for real time datalogging (PC laptop and optional logging cable required)
Please Note: Win98/NT/2000/ME/XP/Vista/Windows 7/8/10 compatible.
Applications
- V6/V8/V10/V12 Engines
Input/Output Range
- Lambda: 1.43 to 0.64 Wideband
- AFR: 21.0 to 9.6 Wideband
- Analog Wideband Outputs: 0 - 5V (configurable)
- Narrowband Outputs: 0 - 1V (configurable rich/lean switching point)
ZR-4 Dual AFR Gauge Specs
- Base Diameter: 2.05" (52mm)
- Bezel Diameter: 2.44" (62mm)
- Thickness: 0.75" (19mm)
- Digit Height: 0.4" (10mm)
What's In The Box?
- 1 - ZT-4 Dual Wideband AFR Meter
- 1 - ZR-4 Dual AFR Gauge
- 2 - 4.9 O2 Sensors
- 2 - O2 Sensor Harnesses (10ft)
- 1 - Signal Harness
- Instructions
References
Warranty
- Manufacturer Standard Warranty
