Precision Turbo 6266 Billet Gen2 CEA BB Turbocharger - 800WHP (505-6266B-GEN2)

PTE's PT6266 Turbocharger

The new Precision Turbo 6266 GEN2 will turn your car into a high-performance race machine! It features cutting-edge compressors and turbine wheel technology that are engineered to provide maximum power. The Competition Engineered Aerodynamics of this product produces both hot and cold sides for a solid operating range.

This higher efficiency turbo has got some serious performance behind it.

PTE's PT6266 Turbo offers a substantially higher horsepower increase than similarly sized turbos, making it the perfect choice for those who want to produce power without changing their systems.

Features

• Exclusive GEN2 CEA (Exclusive CEA) – Competition Engineered Aerodynamics compressor wheel machined from a 2618-aluminum forging
• Higher efficiency and faster transient response for maximum power and extra output performance
• 62mm inducer compressor wheel
• Compressor cover - "Ported S" compressor cover 4.0" inlet/2.5" outlet
• 66mm, 76 trim turbine wheel
• Turbine housing options - T3 .63 or .82 A/R with 4 bolt (2.5") discharge - T3 .63 A/R with 5 bolt discharge (with or without wastegate hole) - T3 .63 or .82 A/R with 3" OD (outer diameter) V-Band discharge - V-Band inlet .82 A/R with V-Band discharge - Stainless steel .82 A/R V-band inlet/outlet - T4 Tangential .58, .68, .81, or .96 A/R with 3 5/8" OD (outer diameter) V-Band discharge - T4 Divided .84, 1.0, 1.15, or 1.32 A/R with 3 5/8" OD (outer diameter) V-Band discharge - Buick .63 or .85 A/R - GMC Syclone/Typhoon .85 A/R - K26 .82 A/R
• Standard with an air-cooled, dual ceramic ball-bearing center housing rotating assembly (CHRA)

Relevant Part Numbers

• Turbine Housing Clamp & Flanges Reference
• Compressor Cover Reference

Applications

• Universal

What's in the box?

• 1 Turbocharger

Warranty

• PTE Limited Warranty

Installation

• Click Here
