Mocal Engine Oil Take-Off Plate | Nissan SR20 (TOP19)

Nissan SR20 Engine Oil Take-Off Plate by Mocal

This plate would be used in place of the stock oil filter mount and provides ports for connection to a remote filter. This would most likely be used in an engine swap situation or when turbo/turbo plumbing is in the way of the stock filter location.

Inlet/outlet ports are M22 x 1.5 with two additional 1/8" NPT ports for gauge or oil feed line (plugs provided). Can be packaged with either 2x -10AN or 2x -8AN (PN# TOP19-8 or TOP19-10) fittings for hose connection. Mounting hardware & O-rings for mounting are provided.

Features

• Used in place of the stock oil filter mount
• Provides ports for connection to remote filter
• M22 x 1.5  inlet/outlet ports
• Two additional 1/8" NPT ports for gauge or oil feed line (plugs provided)
• -8AN or -10AN fittings for hose connection can be included (optional)
• Includes mounting hardware and o-rings

Applications

• Nissan SR20 Engines

What's In The Box?

• 1 - Engine Oil Take-Off Plate
• 1/8" NPT Plugs
• Mounting Hardware & O-Rings
• OPTIONAL - Fittings for Hose Connection

Warranty

• Manufacturer Standard Warranty
