JE Pistons Forged Piston Kit - 4.6in Bore / 1.395in CH / -3.0 CC | 1969 Chevrolet Camaro/Corvette ZL1 (282042)

1969 Corvette/Camaro ZL1 Piston Kit by JE Pistons

As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons’ performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.

Features

• Cylinder Head: Open Chamber
• Bore Diameter: 4.600 IN
• Piston Head Type: Flat
• Compression Height: 1.395 IN
• Piston Volume: -3.00 CC
• Piston Material: 2618
• Forging Type: Round
• Piston Average Weight: 680 GR
• Top Compression Ring Thickness: 0.0640 IN
• Second Compression Ring Thickness: 0.0640 IN
• Oil Ring Thickness: 0.188 IN
• Wrist Pin Length: 2.930 IN
• Wrist Pin Wall Thickness: 0.180 IN

Benefits

• Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
• Designed specifically for each engine and use application to provide optimized performance durability
• Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
• Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
• Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
• Made 100% in the USA

Applications

• 1969 Chevrolet Camaro ZL1
• 1969 Chevrolet Corvette ZL1

What's In The Box?

• 1 - JE Pistons Forged Piston Kit

Warranty

• Manufacturer Standard Warranty
