Innovate LC-2 Digital Wideband "Lambda" O2 Controller w/ 3ft Sensor Cable (3884)
Innovate*SEE DETAILS
LC-2 Digital Wideband O2 Controller by Innovate
The evolution of the world’s most popular stand alone digital O2 sensor controller, the Innovate Motorsports LC-2 builds upon the legacy of the LC-1 by adding simplicity and leading edge technology.
The LC-2 utilizes 100% digital wideband air/fuel ratio technology on the market! The LC-2’s patented award-winning DirectDigital™ signal processing technology provides data on exactly how rich or lean an engine is running at any load. The LC-2’s self-calibrating circuitry also compensates for changes in temperature, altitude, and sensor condition.
The LC-2 includes a digital input/output, 2 full-programmable analog outputs, and is ideal for applications such as dynamometers, data acquisition systems, standalone ECUs, and gauges. The LC-2 can also be "daisy-chained" for cost-effective individual cylinder monitoring, and is fully compatible with our Modular Tuning System (MTS)
Features
- Patented DirectDigital™ Wideband Technology
- Wideband O² Compatible with ALL fuel types
- Ability to calibrate O² sensor for maximum accuracy
- Integrated dual-color status LED (Green/Red)
- *2-Configurable linear 0-5v analog outputs
- Positive lock connectors for all connections
- Innovate MTS serial in/out
- Serial connection to your PC
- Real-time display data on screen and/or with powerful LogWorks software
Please Note: Two fully programmable linear analog outputs to connect to analog gauges, dyno computers, ECUs, piggyback controllers, and other devices with analog inputs. Analog Output #1 (Yellow) is configured as 0 volt = 7.35 AFR and 5 volts = 22.39 AFR; Analog Output #2 (Brown) 1.1 volt = 14 AFR and .1 volt = 15 AFR. With the provided LM Programmer software these analog outputs may also be configured by the user.
Applications
- Universal
What's In The Box?
- 1 - LC-2 Controller
- 1 - Bosch Wideband O2 Sensor
- 1 - 3ft Sensor Cable (Overall Length 5ft)
- 1 - Mild Steel Exhaust Bung
Warranty
- Manufacturer Standard Warranty
Customer Reviews
There are a lot of Innovate haters out there. Most failures are sensor failure due to sensor placement. Even I had my first LSU 4.9 fail with this controller, totally my fault. I installed the bung in a vertical section of exhaust, apparently that's also a no go. Once I moved the sensor location and got a new sensor it's been working great. My old LC1 I had for 10 years and the controller itself failed, once I opened it up I found that the board was corroded inside of the weatherproof case. So just be aware of this potential issue, otherwise I think it's a great product and I would buy it again. Works great connected to my MS3X Megasquirt ECU.
