ACT Sprung Street Disc w/ HD Pressure Plate | 2003-2006 Mitsubishi Evo (ME2-HDSS)
ACT Clutch Kits & Flywheels*SEE DETAILS
Advanced Clutch HD-M/Perf Street Sprung Clutch Kit - ME2-HDSS
ME2-HDSS kit features ACT's most popular Heavy Duty pressure plate and most popular street disc. ACT Heavy Duty pressure plates use exclusive diaphragm design to increase clamp load, reduce deflection and maximize clutch life. All diaphragms endure a four-stage, heat-treating process for unparalleled performance. ACT pressure plates have precision cover stampings to provide rigidity and consistency. ACT's Performance street discs are the most popular disc purchased. They feature premium organic materials with high copper content for better heat transfer and steel-backed lining for greater burst strength and durability. These discs feature a reduced marcel for faster shift action to complement ACT pressure plates. Quiet operation with increased strength and reliability. Monoloc is a one-piece, direct replacement or upgrade to the standard, two-piece wedge collar and wire ring featured in pull-type clutches. The spring tension of the segmented retaining ring is carefully calculated and tested for optimal performance. It provides uniform loading on the bearing and pressure plate to assure proper alignment, regardless of driver influence or vehicle modifications. Monoloc's hardened chrome-moly steel construction will provide years of service.
Features
- Feel: Light to moderate pedal effort, smooth positive engagement, OE to mild gear rattle, confidence during hard shifts;
- Life: Longer friction life, extended by ACT's exclusive diaphragm design, dramatic improvement in release mechanism life;
- Quality: Carefully engineered, precisely assembled, accurately balanced, with premium organic friction materials for heat tolerance and reduced fade, major improvement in release mechanism;
- Recommended Use: Recommended for street and race use;
- ACT Difference: 100% clamp load tested and dynamically computer balanced for smooth high RPM reliability, includes ACT's patented Monoloc
Specifications
- Disc Material: Organic
- Spline Count: 23
- Friction Surface Diameter (Inches): 9.4
- Pressure Plate Type: Heavy Duty
- Input Shaft Diameter (Inches): 1
- Friction Surface Diameter (mm): 240
- Product Weight (lbs.): 17.3
- Disc Type: Sprung Street Disc
- Torque Capacity Over OE: 45%
- Torque Capacity (ft/lbs.): 530
Applications
- 2003-2006 Mitsubishi Evo 8/9
What's In The Box?
- (1) Performance Street Sprung Disc 3000305
- (1) Heavy Duty Pressure Plate MB018
- (1) Release Bearing RB601
- (1) Alignment Tool AT03
Warranty
Resources
Customer Reviews
Great replacement for OEM. Works nice on my Evo 4.
This is my second one, just a rock solid OEM + clutch replacement
Tried numerous clutch. Including competition twin plate etc, only clutch which can hold and longevity is act hdss. Swear by it. Used for almost 2 years without any locking issue. 5th gear downshift into 3rd is always a smooth butter engage. Need some time to get use to it as the holding/biting is abit harder then stock. But not really hard to figure out. Great clutch at affordable range ! I match it up with stock flywheel for daily drive and it work out superb. Tried lightflywheel before and the engage is fast but not smooth enough. Maybe own preference
I have about 1,000 miles and one AutoX event on this clutch. 320whp w/ full bolt-ons. Really liking the feel and engagement on it. It grabs nice but has a pretty stock pedal feel, which is exactly what I was looking for. I did use an OEM Throw Out Bearing for peace of mind. Would definitely buy again!
I had an eBay clutch in the evo beforehand that decided to let go about a week before my event. MAP got the clutch to me just in time to install and make it to the AutoX.
Top price/performance ratio, 95% of the time we only use ACT clutches on our JDM vehicles
